Fiilex Q8 Colour LED Fresnel
Fiilex Q8 Colour LED Fresnel
Regular price
$0.00 (ex GST Per Day)
Regular price
$0.00
Sale price
$0.00
Unit price
per
Couldn't load pickup availability
Description
The Q8 Color is a 320W 8” LED Fresnel that generates high-quality full-color light output. This fixture uses the latest iteration of Fiilex’s Dense Matrix LED technology to deliver color fidelity and optical versatility that are superior to previous generations of LED fresnels. With an extremely wide spot/flood range, smooth dimming to 0%, no flicker, and high CRI, the Q8 Color combines the extensive feature set of top-tier RGBW LEDs with the performance of a tungsten fresnel.
Features
- High-CRI white light output (2000-10000K)
- Additional 8 and 16 bit colour modes: HSI, Effects, RGBW, Gels, CCTHSI, CIExy, etc.
- 12°-62° spot/flood range with no optical aberrations
- 8-leaf barndoor cuts clean with no colour splitting
- Smooth and Sharp dimming modes
- Four fan speed modes: Full, Variable, Silent, Off
- IP-X5 Rating (water-resistant)
- Compatible with industry standard softboxes via speed ring accessory
Specs
| Fresnel Diameter | 8" |
| Beam Angle | 12°-62° |
| CCT Range | 2000-10000K continuous tuning + magenta/green shift |
| CRI | 95 typical. |
| TLCI | 90 typical. |
| Control Modes | CCT, HSI, RGBW, Gels, Effects, CCTRGBW, CCTHSI, CIExy, ICTHS |
| Dimming | 100 - 0% flicker free |
| Dimming Modes | Smooth, Sharp |
| Light Engine | 1x 300W DiCon Dense Matrix LED |
| Power Consumption | 320W max AC | 300W max DC |
| DC Input | 48V DC |
| AC Input | 100 - 240V AC, 50 ~ 60Hz |
| Power Port | XLR-3 |
| DMX Port | XLR-5 |
| Weight | Fixture & yoke: 17lbs / 7.7kg | Power adapter: 4.8lbs / 2.2kg |
| Size (L x W x H) | 13.8" x 12.7" x 19.8" / 35.3cm x 32.3cm x 50.3cm |
| Mount Type | Combo (baby stud female / junior stud male) |
| IP Rating | IP-X5 (water-resistant) |
| Thermal Design | Aluminum extrusion cooling system w/ fan |
| Operating Temperature | 0-40ºC / 32-104ºF |
Photometric Data
